QM-FIT ｜ Enhancing Quality Inspection with a Faster and More Accurate Automatic Measuring System

🔹 Key Takeaways - Automatic camera system detects and measures instantly when a workpiece is placed - Fast measurement without setup or alignment - 20-megapixel color CMOS camera with telecentric lens - Automatic Pass/Fail judgment and measurement record - Complies with Japan’s traceability standards (JCSS, NMIJ/AIST) 🔹 Mitutoyo QM-FIT: Superior Measurement Performance In today’s manufacturing, speed, accuracy, and flexibility are vital. The Mitutoyo QM-FIT vision measuring system answers these needs with the concept of “Place and Measure Instantly.” It minimizes setup time and simplifies operation—ideal for small or thin precision parts. 🔹 New Concept — Place and Measure Instantly Traditional measurement requires complex setup and alignment. With QM-FIT, simply place the workpiece on the stage; the system automatically detects and measures it immediately. This reduces preparation time and accelerates in-line quality inspection. 🔹 High-Resolution Optics for Micron Accuracy A 20 MP color CMOS camera and telecentric lens deliver sharp, distortion-free images with ±10 µm accuracy. The 15.6-inch touchscreen allows intuitive point selection using the Marker- function. 🔹 Automatic Detection, Easy for Everyone QM-FIT recognizes circles, lines, and edges automatically. Users just select the area on screen; results appear instantly with Pass/Fail display and guided instructions. Even non-specialists can measure accurately and consistently. 🔹 Compact, Yet Laboratory-Level Precision At only 366×407×621 mm, QM-FIT fits easily in production lines. It supports JCSS/NMIJ-AIST traceability, ensuring reliable calibration and measurement confidence. 🔹 Before vs. After - Before: Manual setup and alignment needed ➡️ After: Place the workpiece — auto measurement starts - Before: Manual point selection ➡️ After: Detects multiple features automatically - Before: Skilled operators required ➡️ After: Easy touchscreen control for all users 🔹 Applications Ideal for small or thin workpieces needing high resolution—such as PCBs, connectors, and micro molds. Simply place and measure—no setup or predefined points required. 🔹 Reliability According to Mitutoyo (Thailand), QM-FIT combines ease of use with high accuracy for on-site applications. It meets JCSS and NMIJ/AIST standards, ensuring repeatable, traceable measurements. [1][2] 🔹 Summary Mitutoyo QM-FIT unites speed, simplicity, and precision in one automated vision system. It improves quality inspection efficiency and sets a new benchmark for precision measurement in modern manufacturing. 🔹 FAQ Q1: What principle does QM-FIT use? A: A Vision Measuring System that detects and measures automatically. Q2: Does it support traceability standards? A: Yes, compliant with JCSS and NMIJ/AIST. Q3: What workpieces is it suited for? A: Small or thin precision parts like PCBs and connectors. 🔹 Glossary - Vision Measuring System: Camera-based non-contact measurement - Telecentric Lens: Reduces distortion for accurate imaging - Traceability: Ensures calibration accuracy consistency - CMOS Sensor: High-resolution image sensor - Pass/Fail Function: Auto result evaluation - Alignment: Pre-measurement positioning process 🔹 Reference [1] Measuring Machine_QM-FIT_Catalog.pdf – Product Data Sheet: QM-FIT Vision Measuring System,- Mitutoyo (Thailand) (2024) [https://prime.nc-net.com/95281/en/catalog/request/8664] [2] MAP24_D-BOOK_2024E – Mitutoyo Measuring Instruments Catalogue,- Mitutoyo (Thailand) (2024) [https://www.mitutoyo.co.th/th-en] Updated: 2025-11-11 #Mitutoyo #QM-FIT #VisionMeasuringSystem #Traceability #JCSS #NMIJ #QualityInspection #AutomaticMeasurement #PrecisionEngineering #ManufacturingAutomation

Compact CNC Vision Measuring Machine for Small Parts｜High Precision for Medical & Electronics

QUICK VISION Active 202 by Mitutoyo is a compact CNC vision measuring machine engineered for high-precision measurement of small parts. Designed for electronics, semiconductor, and medical device manufacturers, it supports both non-contact and 3D touch-probe measurement methods. Its compact design makes it ideal for production lines with limited space, especially in Southeast Asian factories. ■ Key Features - Automatic edge detection and autofocus reduce operator error - Non-contact and touch-probe (3D) measurement options available - High-resolution CMOS camera with auto zoom lens (0.5X–7X) - User-friendly QVPAK software for automated measurement & reporting - Compact footprint for shop floors or cleanrooms with space constraints ■ Technical Specifications - Measuring Range: 250×200×150 mm - Camera: High-resolution CMOS - Lens: Auto zoom (0.5X–7X) - Models: Standard (non-contact) / Touch-probe (3D contact) - Software: QVPAK - Machine Dimensions: 570 × 767 × 1468 mm ■ Example Applications - Inspection of small electronics like ICs, PCBs, and micro sensors - Measurement of medical parts like drill heads, covers, micro shafts - Dimensional control of gears and miniature shafts for OEMs - Suitable for inline quality control in smart factories ■ Recommended for Industries - Medical device manufacturers - Electronics and semiconductor producers - Precision mechanical part factories - OEM suppliers focusing on high-accuracy inspection With a focus on automated precision measurement and space efficiency, the QUICK VISION Active 202 is the ideal solution for small-part metrology in modern production environments, especially in Asian factories transitioning to Industry 4.0. #CNCVisionMachine #SmallPartsMeasurement #MedicalComponentInspection #HighPrecisionCMM #TouchProbeSystem #ElectronicsInspection #CompactCMM #InlineQualityControl #QVPAKSoftware #MitutoyoThailand

CNC Vision Measuring Machine for Large Workpieces｜QUICK VISION Active 404 with Touch-Probe Option

QUICK VISION Active 404 from Mitutoyo Thailand is a high-precision CNC vision measuring system designed for medium to large-sized parts. With a wide measuring range and support for both non-contact and 3D touch-probe measurement, it offers flexible and automated solutions for automotive, plastic, and OEM industries in Southeast Asia. ■ Key Features - Large measuring range: 400×400×200 mm (or 168 mm Z-axis with 1X lens) - Models available: Standard (non-contact) and Touch-Probe (3D contact) - Optional MCR20 stylus changer for automated multi-point inspections - High-resolution CMOS camera with auto zoom (0.5X–7X) - Powered by QVPAK software for smart measurement automation and reporting - Compact structure optimized for factories with limited installation space ■ Technical Specifications - Measuring Range: 400×400×200 mm 400×400×168 mm (with 1X lens) - Camera: CMOS high resolution - Lens: Auto zoom 0.5X–7X - Models: Standard / Touch-Probe - Accessory: MCR20 stylus changer (Touch-Probe model only) - Software: QVPAK - Dimensions: 776 × 1303 × 1592 mm ■ Example Applications - Inspection of large plastic housings or molded parts - Dimensional verification of automotive brackets and frames - Multi-point inspection of tooling and mechanical components - Inline QC for OEM and contract manufacturing - Ideal for high-mix, low-volume precision production ■ Target Industries - Automotive suppliers and integration companies - Plastic component manufacturers - Electronics and electrical parts factories - Precision mold and die industry - OEM factories in Chonburi, Rayong, Samut Prakan Mitutoyo QUICK VISION Active 404 delivers robust accuracy and automation, making it an ideal tool for factories looking to upgrade to Industry 4.0 and meet high-precision demands in real production environments. #CNCVisionMeasurement #LargeComponentInspection #TouchProbeCMM #QVPAKSoftware #HighPrecisionMetrology #AutomotiveInspection #PlasticPartsMeasurement #InlineQualityControl #SmartFactoryThailand #MitutoyoThailand

QVPAK Intelligent Software in QUICK VISION｜Automated CNC Measurement with High Accuracy

Mitutoyo Thailand's QUICK VISION Series is more than a vision measuring machine—it’s a smart platform powered by QVPAK and QVGraphics software, enabling high-accuracy automated CNC measurement for all skill levels. Ideal for factories aiming to implement smart inspection processes and reduce quality errors on the shop floor. ■ Core Software Built into QUICK VISION 🔹 QVPAK – Centralised Measurement Software - Easy programming for automated and repeatable measurement tasks - Full control of camera, zoom lens, lighting, and probe from one interface - Delivers real-time graphical and numerical measurement results - Supports program recall for batch production inspections 🔹 QVGraphics – Intelligent Image & Contour Analysis - Automatic edge detection and profile recognition - Overlay comparisons with CAD or master images - Detects microscopic deviations not visible to the human eye ■ Key Advantages for Factory Users - Works for all operator levels: From novice to expert, the system suggests optimal measurement settings - Faster results: From measuring to visual reporting—all within a single system - Expandable architecture: Compatible with QV3DCAD, FORMTRACERPAK, and MeasurLink for integrated analysis and factory-wide quality control ■ Ideal For - Factories in electronics, medical devices, and automotive industries - Quality assurance teams requiring reliable and fast results - Facilities implementing Smart Factory and Industry 4.0 standards - Users in Southeast Asia need localised software usability and flexibility QUICK VISION system powered by QVPAK is not just a measurement tool—it's a professional platform engineered to meet modern production challenges with precision, speed, and scalability. #QVPAKSoftware #CNCMeasurement #AutomatedInspection #EdgeDetection #CADComparison #SmartFactoryThailand #MitutoyoThailand #TouchProbeMeasurement #HighAccuracyMetrology #ShopFloorMeasurement

Shop Floor CNC CMM MiSTAR 555｜High-Accuracy Measurement Without Temperature-Controlled Room

The MiSTAR 555 by Mitutoyo Thailand is a shop floor-ready CNC coordinate measuring machine (CMM) built to deliver high-accuracy inspection directly in the production area. Designed for factories in automotive, precision mechanical, and medical industries, it ensures reliable results even in environments without a temperature-controlled room. MiSTAR 555 introduces the "measurement anywhere" concept, featuring real-time temperature compensation and a sealed structure for dust and oil mist resistance. Its compact footprint and air-free design make it ideal for Southeast Asian factories transitioning to Smart Factory or Industry 4.0 environments. ■ Key Features - No inspection room needed – install right next to the production line - Guaranteed accuracy: E₀,MPE = (2.2 + 3L/1000) µm - Compact design – saves up to 20% installation space - No compressed air required – simplifies installation and reduces costs - IIoT and Smart Factory ready – designed for modern manufacturing ■ Technical Specifications - Measuring Range (X × Y × Z): 570 × 500 × 500 mm - Accuracy: E₀,MPE = (2.2 + 3L/1000) µm - Operating Temperature Range: 10°C to 40°C - Installation Footprint: Approx. 1.26 m² - Probe: SP25M (for guaranteed accuracy in 18°C–22°C) ■ Ideal Applications - In-line inspection at the production site - Factories without climate-controlled measurement rooms - Measurement of automotive parts, metal frames, and medical components - Ideal for factories in Thailand and Southeast Asia with limited floor space MiSTAR 555 enables high-precision measurement directly on the shop floor—empowering real-time quality control where it matters most. #ShopFloorCMM #CNCMeasurementMachine #MiSTAR555 #NoAirSupplyRequired #InLineInspection #TemperatureCompensation #HighPrecisionMetrology #AutomotiveCMM #SmartFactoryThailand #MitutoyoThailand

Hybrid Form & Surface Roughness Measuring System｜FORMTRACER Avant Series for CNC Automation

■ Summary Mitutoyo Thailand’s FORMTRACER Avant Series is a hybrid form and surface roughness measuring system that combines two precision functions in one compact unit. Designed for CNC-controlled multi-point inspections, it helps manufacturers reduce measurement time while enhancing consistency and traceability in shop floor environments. ■ Product Overview FORMTRACER Avant is engineered for easy operation and high performance, supporting contour and surface roughness measurement with a smart detector unit. It features real-time switching between modes, automated X-axis movement, and expandable measuring ranges for various component types. ■ Key Features - 2-in-1 hybrid system: Measures both form and surface roughness in one machine - CNC X-axis: Enables fully automated multi-point inspections - Detector options: > Contour: C-3200 / C-4500 > Roughness: S-3000 / S-3000MR and more - Touchscreen UI: Easy operation and automatic stylus configuration - Scalable design: Supports different base sizes and optional accessories like anti-vibration tables, stylus holders, etc. ■ Technical Highlights - Z2-Axis (vertical range): 300 / 500 / 700 mm - X-Axis (horizontal range): 100 mm or 200 mm - Measuring force: Approx. 0.75 mN - Base: 600 × 450 mm (Standard Base Model) - Resolution: Sub-micron level > *Other model variations such as High-column and Large Base types are also available. Please refer to the catalog for full specification ■ Recommended For - Mold and die manufacturers - Precision machine shops working with small-to-medium parts - Factories seeking a space-saving, CNC-integrated measuring solution - Operators who need automated, user-friendly inspection systems FORMTRACER Avant is a future-ready solution for Industry 4.0 factories, offering precise control, fast inspection, and flexible stylus management—all within a compact footprint. #FormMeasurement #SurfaceRoughnessMachine #2in1MeasuringSystem #FORMTRACERAvant #ContourMeasurement #RoughnessInspection #CNCMetrology #ShopFloorInspection #MitutoyoThailand #HighPrecisionMeasurement

What is Metrology?｜Understanding Precision Measurement Tools and Their Role in Thai Industry

Metrology is the backbone of industrial precision, empowering Thai factories with reliable quality control, global compliance, and the foundation for Industry 4.0 transformation. ■ What is Metrology? Metrology is the scientific discipline focused on the measurement of physical properties such as length, weight, angle, and pressure. It ensures that these measurements are accurate, consistent, and traceable to international standards like ISO/IEC 17025. In the manufacturing world, metrology serves as the backbone of quality assurance—enabling manufacturers to validate processes, reduce variability, and comply with global specifications. ■ Why is Metrology Important in Manufacturing? Even small deviations in measurement can lead to costly production errors. In high-stakes industries like automotive or aerospace, these inaccuracies can compromise product performance and safety. Metrology ensures that every component is manufactured within tolerance, enabling: - High product consistency - Reduced waste and rework - Real-time quality control - Seamless integration into Industry 4.0 ecosystems ■ Common Types of Measurement Tools in Metrology 1. Dimensional Tools  – Micrometers, Vernier Calipers, Gauge Blocks, Height Gauges, Coordinate Measuring Machines (CMMs) 2. Mechanical Tools  – Force Testers, Hardness Testers, Torque Meters 3. Non-Contact Tools  – Optical Microscopes, Laser Measurement Devices, 3D Scanners 4. Automated Systems  – In-Line Measurement Systems, Robotic CMM Arms, Smart Sensors Regular calibration is essential to maintain accuracy and compliance with global standards. ■ How Metrology Drives Thai Industrial Innovation Thailand’s push toward Industry 4.0 relies heavily on precision and digital control. Metrology supports: - Real-time quality assurance - Predictive maintenance - Automation and smart factory transformation Sectors such as electronics, aerospace, medical devices, and automotive all depend on high-precision measurement systems to achieve global quality benchmarks. ■ Recommended Partner: MITUTOYO (THAILAND) CO., LTD. MITUTOYO (THAILAND) CO., LTD. is a trusted provider of world-class metrology tools and services. Their product lineup spans manual instruments to advanced automated solutions—CMMs, non-contact systems, and smart sensors—supported by expert calibration and training. With decades of experience in the Thai market and a commitment to micron-level accuracy, MITUTOYO empowers factories to elevate their quality control processes and align with international standards. 🔗 Explore MITUTOYO’s product portfolio here:👉 https://www.mitutoyo.co.th/th-th/product #Metrology #PrecisionTools #Industry40 #SmartFactory #CMM #QualityControl #ThailandManufacturing #Calibration #MeasurementSystems #IndustrialInnovation

What is ISO/IEC 17025?｜Why Calibration Labs in Thai Factories Must Meet This Global Standard

ISO/IEC 17025 certification ensures calibration labs in Thai factories deliver accurate, globally trusted results, boosting quality control, reducing costs, and meeting the demands of high-precision industries. ■ What is ISO/IEC 17025? ISO/IEC 17025 defines the general requirements for the competence of calibration and testing laboratories. It addresses both management systems and technical accuracy, including: - Calibration methods - Staff qualifications - Equipment traceability - Measurement uncertainty - Data reliability Jointly developed by ISO and IEC, this standard is globally recognized in sectors where quality and precision are non-negotiable, like automotive, aerospace, electronics, food processing, and pharmaceuticals. ■ Why Thai Factories Need ISO/IEC 17025-Certified Calibration Labs 1. Proves Professional Competency  Certification confirms the lab meets international criteria for precision and process control. 2. Builds Global Trust  Clients and partners can rely on results from certified labs—no need for repeat calibration overseas. 3. Cuts External Calibration Costs  An internal ISO/IEC 17025 lab minimizes production downtime, logistics delays, and long-term costs. 4. Meets Audit and Compliance Demands  Certified labs align with the quality expectations of global buyers and regulatory bodies. ■ Core Structure of ISO/IEC 17025 1. Management Requirements  Covers document control, recordkeeping, continual improvement, and risk management. 2. Technical Requirements  Focuses on staff competence, validated methods, traceability to standards, and precise uncertainty analysis. These combined elements make results reliable, repeatable, and internationally recognized. ■ How ISO/IEC 17025 Benefits Thai Industries - Automotive: Verifies critical dimensions of shafts, brakes, and safety components - Electronics: Calibrates precision instruments down to micron-level tolerances - Metalworking & Tooling: Ensures accurate operation of CMMs and hardness testers - Food & Pharma: Validates temperature and pressure devices for safety compliance ■ Why MITUTOYO (THAILAND) CO., LTD. is the Trusted Partner for Calibration MITUTOYO (THAILAND) CO., LTD. provides ISO/IEC 17025-certified calibration services, backed by decades of expertise in precision metrology. They calibrate tools such as: - Micrometers - Vernier callipers - Coordinate Measuring Machines (CMMs) All services are delivered by certified engineers who also advise factories on building internal calibration capabilities, improving quality systems, and achieving long-term measurement reliability. 🔗 Learn more about MITUTOYO’s ISO/IEC 17025 certifications and services: 👉 https://www.mitutoyo.co.th/th-en/support/certification-and-accreditations #ISO17025 #CalibrationLab #QualityControl #Metrology #SmartFactory #Traceability #ThaiIndustry #CMM #MeasurementAccuracy #IndustrialStandards

How to Choose the Right CNC Vision Measuring System｜Match Stage Size & Resolution Needs

Selecting the right CNC Vision Measuring System depends on workpiece size, required resolution, and automation needs. This guide helps you make the right investment with confidence. 1. Understand CNC Vision Measuring Systems CNC Vision Measuring Systems are non-contact metrology tools that use cameras and CNC-controlled software to measure workpieces automatically. They are ideal for small to medium-sized parts, especially where precision and surface safety are critical. Unlike traditional touch-based CMMs, these systems: - They are faster and more precise for delicate parts - Avoid workpiece damage - Offer automated, repeatable inspection Core Components: - Optics & Camera for high-resolution imaging - Stage with X/Y/Z movement for positioning - CNC software for measurement programming and reporting 2. Choose Stage Size Based on Your Workpiece Stage size directly affects machine cost and usability. Choose wisely to match your production environment: - Small Workpieces (≤100×100 mm): → Choose compact models like Quick Vision ELF. Great for precision work in limited space, with lower investment cost. - Medium Workpieces (100×100–300×300 mm): → Models like Quick Vision Active or Apex Pro allow multi-part setups and higher throughput. - Large or Sheet-Type Workpieces: → Quick Vision ACCEL supports large-scale measurement with stable XYZ control. > Over-sizing increases cost. Undersizing limits function. Match size to your actual workflow. 3. Match Resolution, Lens, and Focus to Application Needs Precision depends on three main optical features: - Camera Resolution: → A 5MP+ camera enables clear edge detection and submicron measurement. - Zoom Range: → Auto Zoom lenses eliminate the need for manual changes, ensuring seamless multi-scale measurement. - Auto Focus: → Essential for parts with depth changes. Ensures accuracy and repeatability. For ultra-precision needs such as semiconductors or micro-mechanical parts, go for Quick Vision Hyper Pro, capable of submicron-level accuracy. 4. Maximise CNC Automation Benefits In high-volume or repeat inspection environments, CNC automation provides: - Consistent, operator-independent measurement - Time-saving automated programs - Real-time reporting and SPC/MES integration Ensure the system includes user-friendly software so multiple users across shifts can operate it efficiently. 5. Prioritise Reliable Service and Calibration Support CNC Vision Measuring Systems require regular calibration and professional maintenance. Choose a brand that offers: - Local technical support - Certified calibration services - On-site training and fast response times 👉 Mitutoyo Thailand provides all of the above, ensuring low downtime and long-term measurement accuracy. ■ Why Choose Mitutoyo Quick Vision Series? Mitutoyo is a global leader in precision metrology. The Quick Vision Series is trusted by top manufacturers in: - Electronics - Automotive - Mould and die Key Benefits: - Precision down to the submicron level - Auto Zoom & Auto Focus - Wide stage size options - Local support from Mitutoyo Thailand - Seamless software integration with SPC and factory systems 📌 Learn more or request a product demo: 🔗 Visit the official Quick Vision Series page: https://www.mitutoyo.co.th/th-th/campaign/qv-active #CNCVisionSystem #PrecisionMeasurement #NonContactInspection #QuickVision #MitutoyoThailand #IndustrialMetrology #WorkpieceInspection #CNCMeasurement #FactoryAutomation #SubmicronAccuracy

Precision Measurement for New Energy Vehicle (NEV) Manufacturing｜Mitutoyo Solutions

NEV manufacturing demands higher accuracy, speed, and flexibility. Mitutoyo delivers advanced measurement solutions tailored to battery, motor, and inverter inspection for next-gen electric vehicles. 1. The Rise of New Energy Vehicles New Energy Vehicles (NEVs)—including BEVs, HEVs, and FCEVs—are transforming the automotive industry. This shift impacts not just propulsion systems but also manufacturing methods, materials, and quality control standards. As production complexity grows, so do the requirements for tight tolerance, lightweight design, and traceable precision. This makes advanced metrology a key pillar in ensuring NEV reliability and performance. 2. Key Measurement Challenges in NEV Manufacturing NEV components require micron-level inspection for performance and safety: - Battery packs: Large flat surfaces, sensitive assemblies - e-Drive systems: Tight geometrical tolerances, rotating parts - Inverter housings: Complex castings, thermal interfaces Traditional tools fall short in terms of speed, precision, or non-contact capability. Advanced solutions are needed to inspect without causing part damage or delays. 3. How Mitutoyo Supports NEV Manufacturers Mitutoyo offers comprehensive systems for each critical NEV area: - Battery & Modules: → Non-contact CNC Vision Systems to inspect flatness, curvature, welds → Micron-level dimensional checks without touching fragile parts - Motor & Rotor Shafts: → High-speed CMMs for roundness, concentricity, alignment → Inline measurement to reduce scrap and inspection time - Inverters & Housings: → Multi-sensor systems: 3D probing + imaging + auto tool switching → Accurate angle, profile, and fixture-point verification 4. Automation, SPC, and Data Integration Mitutoyo is automation-ready with digital solutions that align with smart manufacturing: - MeasurLink SPC: Real-time data analysis and process monitoring - MES/ERP Integration: Quality data flows to factory systems - Inline Inspection: Robots + auto-measurement for 24/7 accuracy This reduces human error and enables faster, data-driven decision-making across production lines. 5. Mitutoyo Thailand: Local Support You Can Rely On NEV success depends on consistent, accurate measurements—Mitutoyo Thailand provides: - Certified in-country calibration and maintenance - Expert application engineers for solution development - Structured training programs for equipment and software use ■ Why Mitutoyo Is the Right Partner for NEV Metrology As a global metrology leader, Mitutoyo delivers precision tools, automation readiness, and responsive local service to help NEV manufacturers stay competitive. ✔ Trusted by electronics and automotive giants ✔ Full-range solutions for every NEV measurement challenge ✔ Local support from Mitutoyo Thailand 🔗 Explore Mitutoyo’s NEV Solutions: 👉 [https://www.mitutoyo.co.th/th-th/solutions/mitutoyo-industry-support-new-energy-vehicle] #NEVmetrology #EVmanufacturing #MitutoyoThailand #BatteryInspection #EVcomponents #PrecisionMeasurement #InlineInspection #SmartFactory #CMMsolutions #NonContactMeasurement
