The IKO Linear Way U Series introduces a new design approach for linear motion guides, featuring a U-shaped track rail. This innovative structure significantly enhances rigidity against moments and torsion, enabling use in cantilevered or double-supported configurations. The track rail can also serve as a structural component of machines or devices, increasing assembly flexibility. The slide unit, incorporating two rows of large-diameter steel balls with four-point contact, ensures stable high precision and rigidity even under varying load directions or combined loads.

■ Features
U-Shaped Track Rail: Improved rigidity against moments and torsion allows for cantilevered or double-supported mounting.
High Precision and Rigidity: Two rows of large-diameter steel balls with four-point contact ensure stable load handling and precision.
Compact Design: Low cross-sectional height supports the miniaturization and weight reduction of machinery and devices.
Steel Ball Retention Mechanism: The slide unit includes a ball retention band for easy handling.
Machining Flexibility: The track rail can accommodate additional machining to directly mount drive systems or peripheral components (*excluding the area near the track).

■ Specifications
Track Rail Shape: U-shaped cross-section
Slide Structure: Two rows of large-diameter steel balls with four-point contact
Applications: Industrial machinery, conveyance systems, precision equipment, manufacturing devices
Machining Capability: Direct mounting of drive mechanisms (*excluding areas near the track)

■ IKO Thompson Asia Coverage
Thailand: Based in Bangkok, covering Chonburi, Ayutthaya, Samut Prakan, and surrounding regions
Singapore
Malaysia: Kuala Lumpur, Penang, and surrounding regions
Indonesia: Jakarta and surrounding regions
Vietnam: Ho Chi Minh City, Hanoi, and surrounding regions
India

The IKO Linear Way U Series, with its U-shaped track rail, offers enhanced design flexibility, high rigidity, and precision, making it ideal for applications requiring robust and compact linear motion guides.

For more details, download the PDF or contact us directly.

■ Note
"Linear Way" is a trademark of IKO and is distinct from LM Guides or Linear Guides.
